Battery Voltage:12VDC
Continuous Output Power:2000W
Surge Power (Peak):4000W
Operating Voltage (DC Input):9.5 – 16VDC
Output Voltage:120VAC
Output Waveform:Pure Sine Wave
Output Frequency:60Hz
Efficiency (Full Load):90%
AC Current:16.6A
Battery Low Voltage Alarm:9.8V (±0.5V)
Battery Low Voltage Shutdown:9.5V (±0.5V)
Low Input Voltage Shutdown:9.5V (±0.5V)
High Input Voltage Shutdown:16V
Min. Operating Temperature (No Load):0ºC (32ºF)
Max. Operating Temperature (Full Load):40ºC (104ºF)
Weight:11.8 lbs
Depth:17.1 in
Width:9.4 in
Height:3.9 in
